Eddy Current Flaw Detector MEC100P

Description:

MEC-100P Portable Eddy Current Flaw Detector commonly used in war industry, aviation ,railway ,industrial and mining enterprises in the field or on-site. It is a multi-functional, practical, high Cost-effective apparatus. it has many years of manufacturing experience in eddy current detector, meeting the needs of all types of users. it can be widely used in various types of non-ferrous metal, ferrous metal pipes, rods, wire, wire, profiles online and offline testing. It has a high defect detection sensitivity in metal tubes, rods, wire, wire, profiles of the defects such as surface cracks, dark crack, crack open the folder.

  It provides windows in Chinese user interface, Modular way of operating, a variety of display modes for choosing and applying all-digital design techniques. We needn’t readjust the equipment when changing product specification, realized a fool-type operation.

Applications:

1,Bearing outer ring, Bearing inner ring, Gear Blanks, Ring-shaped metal parts , Auto Parts

2,Brass, steel, stainless steel pipe, welded pipe, aluminum tube, steel wire, double pipe, copper Clad Aluminium, Copper Clad Steel, Metals such as Wire Rod Production Line on-line and off-line nondestructive testing

3,Nondestructive testing such as Oil casing, sucker rods, hollow shaft

4,Detection such as Condenser tubes, air conditioner pipe, auto Tubing

5 ,Be suitable for all kinds of Metal wire rod and bar tube nondestructive testing

Specifications:

1,   Detection speed:0.1m/min~500m/min

2,   Frequency range:100HZ~1MHZ

3,   Gain:0~60dB, adjust the volume of 1dB / file

4,   Band-pass filter or the speed of matching

5,   All-digital computer parameter adjustment

6,   Real-time impedance flat panel display

7,   The provision of X-t, Y-t, V-t three time base scan for the choice of real-time display mode

8,   Automatically record and display the location of defects

9,   Marking the dynamic fixed-length feature(no need for the high-speed testing)

10, Function of the head and tail signal resection

11, High-precision real-time and delay alarm output

12, Number of phase and amplitude alarm technology

13, Date and time display Automatically

14, Eddy current testing signal playback, analyze, save and print functions

15, Windows user interface, modular man-machine dialogue

16, Power Supply:180V~240V 50HZ

17, The temperature of environment:-20°C~+40°C
